SICK DBS36E-S3AK00100 - Rotation-Speed-Detect/TTL-Pulse-Signal-Output - Compact 36mm Metal 100PPR Solid Shaft Industrial Encoder
Product Overview
The DBS36E-S3AK00100 is a 36mm compact incremental encoder featuring HTL 10-30V, 100 ppr, clamp flange, 6mm solid shaft, axial M12-8, IP65/IP67, -20…+70°C operation.
Application & Benefits
Provides low-resolution speed and pulse count feedback to drives and PLCs in applications such as conveyors, packaging, and light assembly systems where 60mm DFS encoders won't fit. The 36mm body with 6mm shaft saves valuable space, while the 100 ppr resolution is sufficient for basic speed control—offering a compact, cost-effective alternative to DFS60 models.
Technical Specifications
| Parameter |
Specification |
| Model / Order No. |
DBS36E-S3AK00100 / 1060535 |
| Product Type |
Incremental encoder, mechanical |
| Resolution |
100 pulses per revolution (PPR) |
| Output Interface |
TTL / RS-422 |
| Supply Voltage |
4.5 … 5.5 V DC |
| Shaft Type / Diameter |
Solid shaft / 6 mm |
| Connection |
Cable, 8-wire, 1.5 m |
| Enclosure / IP Rating |
IP65 |
| Operating Temperature |
-20 … +85 °C |
| Max. Speed |
8,000 rpm |
