Hikrobot MV-CH050-10UP, Image Capture, Pixel Data Output, Alloy 5MP PoE Industrial Area Scan Camera
MV-CH050-10UP — 5MP USB3.0 Polarized Industrial Camera
The Hikrobot MV-CH050-10UP is a 5MP polarized USB3.0 industrial camera featuring Sony IMX250MZR sensor, 2448*2048 resolution @ 74.1 fps, global shutter, and C-Mount lens compatibility.
Application & Edge — Polarization Reveals the Invisible
Excels at glass inspection, reflective-surface defect detection, and stress analysis. Four-direction pixel-level polarizers capture polarization data; USB3 Vision-compatible with compact 29mm design.
Product Specifications
| Parameter |
Specification |
| Model |
MV-CH050-10UP |
| Name |
5 MP USB 3.0 Area Scan Camera, Polarization, IMX250, V4 |
| Sensor |
Sony IMX250MZR CMOS, Global Shutter |
| Resolution |
2448 (H) * 2048 (V) (5.0 MP) |
| Max. Frame Rate |
74.1 fps @ 2448 * 2048 (Mono 8) |
| Pixel Size |
3.45 μm * 3.45 μm |
| Sensor Size |
2/3″ |
| Dynamic Range / SNR |
71 dB / 40 dB |
| Data Interface |
USB 3.0 (compatible with USB 2.0) |
| Lens Mount |
C-Mount |
Packaging & Shipping
Company Introduction
Xiamen Zhicheng Automation Technology Co., Ltd. is a professional supplier of industrial automation products and solutions, dedicated to providing reliable, cost-effective, and high-performance products to customers worldwide.
With extensive experience in industrial automation and process control, we specialize in supplying a comprehensive range of automation components for industries such as oil & gas, power generation, petrochemical, water treatment, manufacturing, and industrial infrastructure.
Our Main Products
- PLC Interface Modules
- I/O Systems and Interface Solutions
- Signal Isolators and Signal Converters
- Relays and Relay Modules
- Industrial Power Supply Units
- Control Valves and Actuators
- Industrial Pumps
- Process Instrumentation
Why Choose Us
- Professional industrial automation supplier
- High-quality products with competitive pricing
- Fast response and technical support
- Reliable supply chain and stable product availability
- Customized solutions for industrial applications
- Global export experience and customer-oriented service
We are committed to helping customers improve operational efficiency, system reliability, and process performance through dependable automation products and professional support.
Whether you are an end user, system integrator, engineering contractor, or distributor, Xiamen Zhicheng Automation Technology Co., Ltd. is ready to become your trusted partner in industrial automation.
