+GF+ 3-9900.398-1 - Signal-Split/Dual-4-20mA-Output - Plug-In Loop Powered Single Channel 9900 Transmitter Analog Expansion Module

  • 1
  • 2
  • 3

Model Number : 3-9900.398-1

Supply Voltage : 10.8 to 35.2 VDC

Payment Terms : T/T

Product Type : 4–20 mA Output Expansion Module

Number of Outputs : 1 Additional Analog Loop

Price : USD 100-10000/Piece

Compatible Device : Signet 9900 Transmitter (Generation III+)

Supply Ability : 1/piece in stock

Product Model : +GF+ Signet 3-9900.398-1

Brand Name : +GF+

Application Function : Analog Signal Expansion for Process Control

MOQ : 1

Delivery Time : 3-7

Installation Type : Plug-In Field-Installable Module

Packaging Details : 50*50*50mm

Output Signal : Additional 4–20 mA Analog Output

Place of Origin : USA

Certification : 3C

Contact Now

+GF+ 3-9900.398-1 - Signal-Split/Dual-4-20mA-Output - Plug-In Loop Powered Single Channel 9900 Transmitter Analog Expansion Module
Plug-In 2nd 4-20 mA Output Module for 9900 Transmitter

The +GF+ Signet 3‑9900.398‑1 is an optional plugin 4-20 mA output module that adds a second isolated loop output to a 9900 (Gen III+) base unit, letting you route primary or secondary measurement independently to a second PLC/recorder.

Key Benefits and Applications

This module enables dual-analog distribution (e.g., flow to one loop, pH/temp to another) with independent error-current settings, so you avoid Y-splitting and keep each loop tuned, traceable, and scalable.

Product Specifications
Parameter Specification
Product Type 4 to 20 mA Output Module
Model / Part No. 3-9900.398-1
Order Code 159 001 784
Description Adds a second 4 to 20 mA loop output to a 9900 Transmitter
Compatibility Signet 9900 Transmitter (Generation III or later)
Key Feature Provides a second, independent 4-20 mA output
Power Can be powered using loop power or DC power from the 9900 base unit
Output Assignment Can output the primary or secondary measurement of the connected sensor
Installation User-pluggable module
Compatible Transmitters Panel Mount: 9900-1P; Field Mount: 9900-1
Cable / Connector Includes open collector plug (2-position, right angle)
Packaging & Shipping
